?輸入信號格式：12/3G-SDI、HD-SDI、SD-SDI、4KHDMI、DVI、VGA、YPbPr、CVBS；
?光纖輸入信號格式：SDI、DVI、VGA、4KHDMI、YPbPr、CVBS；
?網絡輸入信號格式：HDBaseT；
?輸出信號格式：12/3G-SDI、HD-SDI、SD-SDI、4KHDMI、DVI、VGA、YPbPr、CVBS；
?光纖輸出信號格式：SDI、DVI、VGA、4KHDMI、YPbPr、CVBS；
?網絡輸出信號格式：HDBaseT；
?矩陣規模：8×8～72×72；
?具有一卡兩路，可靈活配置，支持圖像最高分辨率3840×2160@60Hz，并符合VESA和HDTV全部常規標準；
?向下兼容各種信號格式的分辨率和刷新頻率，具有自動統一信號格式輸出上屏，以及依據用戶需求手動調節的倍線功能；
?支持網絡視頻的解碼顯示，支持H.264和H.265網絡攝像機直接解碼顯示，支持自動解析，支持標準ONVIF，RTSP，TCP，UDP等多種網絡協議；
?光纖板卡支持單模和多模的兩種模式；雙絞線板卡支持HDBaseT技術；
?具有信號均衡補償、修正、自動調節和時鐘恢復功能，確保信號轉換切換后無損耗；
?輸出板卡具有時基校準同步功能，在切換畫面的瞬間，盡最大可能保持畫面的完整，保證切換瞬間畫面無抖動，達到真正的“無縫”切換；信號切換響應速度15ms;
?支持預案保存及調用，預案保存數量2000個，調用時間8ms；
?提供多種通訊方式：RS-232控制和Ethernet控制；
?提供多種控制方式：外置專用面板控制和專用軟件控制；
?支持信號窗口拼接、疊加、漫游、切換功能；
?支持專用軟件控制，實時監測矩陣工作狀態，對輸入、輸出板卡進行參數處理；
?模塊化前后插板式結構設計，信號接口與信號板卡一體化，冗余式雙電源、雙控制系統；
?支持帶電熱插拔、掉電記憶、斷電保護功能，提高系統的穩定性和可靠性；
?具備輸入預監輸出回顯功能，回顯圖像清晰流暢:支持全色度取樣的圖像無損處理，及4:4:4采樣不抽幀處理；
?支持多用戶同時登陸，操作實時同步顯示，不同端口切換不影響其他用戶操作，可同時響應12條命令的切換；
?90～260V/AC 50/60Hz電源，適用于全球范圍；
? Input signal format: 12/3G-SDI, HD-SDI, SD-SDI, 4KHDMI, DVI, VGA, YPbPr, CVBS;
? Fiber input signal format: SDI, DVI, VGA, 4KHDMI, YPbPr, CVBS; ? Network input signal format: HDBaseT;
? Output signal format: 12/3G-SDI, HD-SDI, SD-SDI, 4KHDMI, DVI, VGA, YPbPr, CVBS;
? Fiber output signal format: SDI, DVI, VGA, 4KHDMI, YPbPr, CVBS; ? Network output signal format: HDBaseT;
? Matrix size: 8×8 ~ 72×72, 144×144 ~ 320×320, customization for larger;
? One board has two channels, easy for flexible configuration. Support the highest resolution of 3840×2160@60Hz, and in line with all conventional VESA and HDTV standards;
? Downward compatible with the resolution and refresh frequency of various signal formats, with automatic unified signal format output on the screen, and manually adjusted line doubling function according to user needs;
? Support network video decoding display, support H.264 and H.265 network camera direct decoding display, support automatic parsing, and support standard ONVIF, RTSP, TCP, UDP and other network protocols;
? Fiber optic board supports single mode and multi-mode; twisted pair board supports HDBaseT technology;
? With the function of signal equalization compensation, correction, automatic adjustment and clock recovery, ensure that there is no loss after the signal conversion;
? The output board has the time-based calibration synchronization function, in the moment of switching images, as far as possible to maintain the integrity of the screen, to ensure that the screen at the switching moment without jitter, to achieve a real "seamless" switching. Signal switching response time is 15ms;
? Support preset saving and calling. Preset saving number can be up to 2000. Calling time costs 8ms;
? Provide a variety of communication methods: RS-232 control and Ethernet control;
? Provide a variety of control methods: external specialized panel control and specialized software control;
? Support signal window splicing, superposition, roaming, switching functions;
? Support specialized software control, real-time monitoring of matrix working status, input and output board parameter processing;
? Modular front and rear plug-in plate structure design, integration of signal interface and signal board, redundant dual power supply, dual control system;
? Support plug with electric, power off memory, power off protection, improving the stability and reliability of the system;
? With input pre-monitoring output echo function, the echo image is clear and smooth: support full chrominance sampling image lossless processing, and 4:4:4 sampling without frame processing; ? Support multi-user login at the same time, synchronous display of real-time operation. Switching by one user does not affect other users’ operations. It can respond to 12 commands at the same time;
?90 ~ 260V/AC 50/60Hz power supply, suitable for global scope.
